- Track L-Band CW Beacon Carrier; BPSK Carrier
- Synthesized Direct conversion tuner system
- Serial text-based API interface for easy implementation with simple embedded processors
- Comprehensive API on USB for easy development
- Extended Temperature Range
- Low SWaP-C
- Two enclosure options available
LBR-2195A
The LBR-2195A is a satellite beacon receiver that provides DC output voltage proportionate to the input RF signal level over L-Band. The receiver will remain locked on the CW carrier signal and provide the DC output voltage relative to input RF level at the tuned center frequency. The LBR-2195A can also lock on and track BPSK type modulated carriers signals with excellent
performance. Typical time-to-lock period is <3 seconds. The LBR-2195A has been designed with the systems integrator in mind for satellite antenna and uplink power controller systems. The small form-factor is ideal for low-profile and restricted spaces.
RF SPECIFICATIONS |
|
INPUT CONNECTORS: | SMA, 50 Ohm, DC Blocked to 25V |
INPUT FREQUENCY RANGE: | 950 to 2150 MHz |
TUNING STEP SIZE: | 1kHz |
INPUT LEVEL RANGE: | -30 to -90 dBm |
MAXIMUM INPUT POWER LEVEL: | -20 dBm max |
DETECTION BANDWIDTH: | 10 to 750 kHz |
TRACKING BANDWIDTH: | 10 to 150 kHz |
DETECTED LEVEL FILTERING: | Low-Pass, User-Select: 0.25 Hz, 0.5 Hz, 1.0
Hz, 2.0 Hz, 3.0 Hz |
SEARCH/TRACK RATE: | User-Selectable: 10 Hz |
ACQUISITION TIME: | <1 second typical |
ADJUSTABLE DELAY BEFORE LOCK: | 0 to 5000 milliseconds |
ACQUISITION/TRACKING LEVEL: | Minimum C/No, 39 dB-Hz |
BEACON/CARRIER TYPE: | CW, BPSK (No Demod), CEPT(Carrier-Edge- Power-Track) on DVB (No Demod) |
COMMUNICATION INTERFACE |
|
SERIAL: | RS422, RS232, and RS232 Data Stream, 115200 8n1, (DB-25 Male) |
USB: | 115200 8n1, (DB-25 Male) |
BEACON RECEIVER OUTPUTS: | Analog and Digital outputs, (DB-25 Male) |
M & C |
||||
EVO GUI |
POSIX-C API SBS2API | TEXT-BASED API |
WEB-GUI |
|
SERIAL: | N/A | Yes | Yes | N/A |
USB: | Yes | Yes | Yes | N/A |
RECEIVER OUTPUTS |
|
CONNECTOR: | DB-25 Male |
ANALOG SIGNAL STRENGTH INDICATOR OUTPUT: | 0 to 10 VDC, 10 mA |
ANALOG SLOPE: | 0.1 to 3.0 Volts/dB |
ANALOG SLOPE POLARITY: | Positive or Negative |
ANALOG OUTPUT FILTERING: | Low-Pass, 0.5 Hz, fixed. |
DIGITAL LOCK INDICATOR OUTPUT: | 0 – 3.3 VDC |
DIGITAL LOCK INDICATOR OUTPUT POLARITY: | Adjustable (H=LOCK or L=LOCK) |
ALARM RELAY | Form C, NC and NO |
POWER |
|
CONNECTOR: | 2-pin Molex |
POWER SUPPLY: | 8.0 – 33.0 VDC, <3 W with reverse polarity, surge, and spike protection |
PHYSICAL |
|
DIMENSIONS: | BLK: (4.75″L x 4″W x 1.07″H)
CLM: (5.5″L x 4.5″W x 0.94″H) |
WEIGHT: | BLK: 13oz; 368.5g CLM: 12oz; 340g |
ENVIRONMENTAL |
|
OPERATING TEMPERATURE: | -30°C to 60°C |
STORAGE TEMPERATURE: | -40°C to 85°C |
HUMIDITY: | 0 to 95%, non-condensing |
MODEL OPTIONS |
||
PRODUCT NAME | – | OPTION |
LBR-2195A | – | BLK: Nickel Plated Machined Blocks |
CLM: Painted Metal enclosure |
Avcom Text-based API
Version 5.1
The text-based API allows users to interface using simple text commands. These commands are supported over USB, RS232, and RS422. Users can read and write settings over a terminal or integrate the commands into their system.
Supported Products
- LBR-2195A
- BR-MOD-1-9-B
- SA-MOD-1-9-B
The text-based API is recommended for beacon receiver applications that need a simple status output and may not be able to use Ethernet and/or TCP sockets. For details on the output options and a list of the available commands, please download and read the following user guide:
To include it in your application please download the zip file and include the aov_text_cmds.h
. This file has a macro definition of all the commands to make integration easier.
Text-Based API - 2024
